The G30E II is the European version of the Ninebot G30 II.

It is the second body revision of the Ninebot G30E, with only minor cosmetic differences from the previous version.

The Ninebot G30E II via Segway[1].

The main page for guides relating to this model is at Ninebot Max Stuff.

The G30E II is the german version of the max. Other versions include the G30P II/G30 II and G30D II.

The "E" signifies that this is the G30 version conforming to European safety regulations for speed and design.

The "II" Signifies that this is the second-gen body.

Specifications

Original specs via Segway.

Ninebot G30E II
Dimensions Unfolded: ~45.9 x 18.6 x 47.4 in (1167 x 423 x 1203 mm)
Folded: ~45.9 x 18.6 x 21.0 in (1167 x 423 x 534 mm)
Net Weight Approx. 41.2 lbs (18.7 kg)
Rider Weight 66.1-220.5 lbs (30.0-100.0 kg)
Max Speed Approx. 15.5 mph (25 km/h)
Advertised Range Approx. 40.5 miles (65 km)
Max Slope Approx. 20%
Traversable Terrain Asphalt/flat pavement; obstacles ≺ 0.4 in (1 cm); gaps ≺ 1.2 in (3 cm)
Operating Temperature 14–104°F (-10–40°C)
Storage Temperature -4–122°F (-20–50°C)
IP Rating IPX5
Charge Time Approx. 6h
Battery Voltage 36 VDC
Charging Voltage 42 VDC
Charging Temperature 32–104°F (0–40°C)
Battery Capacity 15300 mAh / 551 Wh
Motor Power 350W (Max 750W)
Internal Charger Power 121W
Internal Current 2.9A
Shocks None
Tires Tubeless tire, Material: Natural carbon-black synthetic rubber, 60/70-6.5. Straight nozzle

Files

Custom Firmware (CFW) Support

ScooterHacking.org currently has support for the first gen ESC of this model in their CFW Generator available at max.cfw.sh.

For more info and help identifying which ESC you might have visit Ninebot Max ESC Generations.

Once converted, CFW can be generated and flashed using the guides below:

CFW usually refers to custom firmware for the ESC or DRV, though there are some CFW versions for BLE and BMS.

ScooterHacking also supports this model with their SHFW.
